Service Accessories
Showing 1–24 of 33 results
-
P&M, Service Accessories
P&M 4-Way Reversing Valve – Model WRV-05
Service Accessory
Reversing Valve Principally Technology Parameter
UPC No. Item No. Port Size (mm) Allowable Substance Nominal Capacity (KW) Connection Slodering ODF Pressure Differential Max. Operating Pressure (Mpa) Max. Fluid Temperature (oC) Voltage Inside Leakage (ml/min) Allowable Power (HP) Charge Discharge (mm) (in.) (mm) (in.) Max. (Mpa) Max. (Mpa) 50700 WRV-05 8 R22 R134 R407C 4.7 8 5/16″ 9.5 3/8″ 22.5 0.25 2.9 -20oC – +120oC AC220 or AC110 < 1000 3/4 ~ 1.2 50701 WRV-09 11.1 9 9.5 3/8″ 12.7 1/2″ 0.25 < 1500 3/4 ~ 2 50702 WRV-11 11.5 11 12.7 1/2″ 15.9 5/8″ 0.34 < 2000 2 ~ 4 50703 WRV-20 15.5 20 12.7 1/2″ 19.05 3/4″ 0.34 < 4000 3 ~ 8 50704 WRV-34 20 34 19.05 3/4″ 22.2 7/8″ 0.34 < 6000 7.5 ~ 12 50705 WRV-45 25 45 22.2 7/8″ 28.6 1-1/8″ 0.34 < 6000 8 ~ 15 50706 WRV-05A 8 R410A 6 8 5/16″ 9.5 3/8″ 3.1 0.34 4.15 -20oC – +120oC AC220 or AC110 < 1000 3/4 ~ 1.2 50707 WRV-09A 11.1 12 9.5 3/8″ 12.7 1/2″ 0.34 < 2000 3/4 ~ 1.5 50708 WRV-11A 11.5 14.5 12.7 1/2″ 15.9 5/8″ 0.4 < 2000 1 ~ 2 50709 WRV-20A 15.5 27 12.7 1/2″ 19.05 3/4″ 0.4 < 4000 4 ~ 8 50710 WRV-34A 20 45 19.05 3/4″ 22.2 7/8″ 0.4 < 5000 8 ~ 15 50711 WRV-45A 25 60 22.2 7/8″ 28.6 1-1/8″ 0.4 < 6000 15 ~ 20 AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50700 -
-
-
P&M, Service Accessories
P&M Capillary Tube With Nuts – Model 1500M
Service Accessory
Capillary tube with nuts, length 1500mm total a twisting of the capillary tube duning connection is excluded. To prevent loss of refrigerant when changing any controls and to connect pressure-switches, gauges etc. on your systems. Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50656 -
P&M, Service Accessories
P&M Capillary Tube With Nuts – Model 900M
Service Accessory
Capillary tube with nuts, length 900mm total a twisting of the capillary tube duning connection is excluded. To prevent loss of refrigerant when changing any controls and to connect pressure-switches, gauges etc. on your systems. Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50654 -
P&M, Service Accessories
P&M Capillary Tube With Nuts – Model 900M-B
Service Accessory
Capillary tube with nuts, length 900mm total with depressor a twisting of the capillary tube duning connection is excluded. To prevent loss of refrigerant when changing any controls and to connect pressure-switches, gauges etc. on your systems. Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50655 -
P&M, Service Accessories
P&M Control Valve (Compress valve) – Model RCV-04
Control Valve
Control valve (Compress valve) 1/4 MFL x 1/4 FFL Close valve core and controls refrigerant flow from access fitting, also retain refigerant in hose when disconnecting. (Dia.: 32 x 66 m/m). Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 30102 -
P&M, Service Accessories
P&M Control Valve (Compress valve) – Model RCV-05
Control Valve
Control valve (Compress valve) 5/16 MFL x 5/16 FFL Close valve core and controls refrigerant flow from access fitting, also retain refigerant in hose when disconnecting. (Dia.: 32 x 66 m/m). Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 30103 -
P&M, Service Accessories
P&M Filter Driers – Model 032 SAE
Filter Driers
Filter driers (charged with molecular sieve) All driers with acid resistant coating
UPC No. 50300 50301 50302 50303 50304 50305 Item No. 032 SAE 032S ODF 052 SAE 052S ODF 083 SAE 083S ODF Connection 1/4 1/4 1/4 1/4 3/8 3/8 Length inches 4.19 3.81 4.75 2.44 2.62 2.62 Diameter of body inches 1.75 1.75 2.44 2.44 2.62 2.62 Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50300 -
P&M, Service Accessories
P&M Filter Driers – Model 164 SAE
Filter Driers
Filter driers (charged with molecular sieve) All driers with acid resistant coating
UPC No. 50306 50307 50308 50309 50310 50311 50312 50313 Item No. 084 SAE 084S ODF 163 SAE 163S ODF 164 SAE 164S ODF 165 SAE 165S ODF Connection 1/2 1/2 3/8 3/8 1/2 1/2 5/8 5/8 Length inches 6.06 5.25 6.94 6.0 6.94 6.0 7.25 6.31 Diameter of body inches 2.62 2.62 3.00 3.00 3.00 3.00 3.00 3.00 Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50310 -
P&M, Service Accessories
P&M Flush Adapter Kit – Model FAK
Flush Adapter Kit
Flush adapter kit in Dubai For most A/C line, tube ends system flushing Kit contents: 8 pcs support plates (3/8″, 1/2″, 5/8″ & 3/4″) and 2pcs clamp assembly. Brothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 30110 -
-
-
P&M, Service Accessories
P&M High Side Coupler – Model QC-16-H
Service Accessory
UPC No. 30112 Item No. QC-16-H High side coupler used for R1234yf service ports 12mm x 1.5 female thread with 1/4” SAE adapterBrothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 30112 -
-
P&M, Service Accessories
P&M Low Side Coupler – Model QC-16-L
Service Accessory
UPC No. 30111 Item No. QC-16-L Low side coupler used for R1234yf service ports 12mm x 1.5 female thread with 1/4” SAE adapterBrothers AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 30111 -
-
P&M, Service Accessories
P&M Potential Relay – Model PM-A3C2
Service Accessory
UPC No. 50800 50801 50802 50803 50804 50805 Item No. PM-A3C2 PM-A3D3 PM-A3R3 PM-A4A3 PM-A4D3 PM-A5C2 H.P. 3/4, 1, 1-1/2, 2 3/4, 1 1/2, 3/4, 1, 1-1/2 2, 3, 4, 5 1-1/2, 2, 3, 4, 5 1/2, 3/4, 1 Vlots 208/230 230 115 230 230 230 Continuous 332 332 332 502 502 253 Pick-up 280-309 299-327 171-184 239-268 295-324 278-306 Drop out 55-100 55-100 40-90 60-135 60-135 35-77 AC Spare Parts Suppliers in Dubai – P&M HVAC Service Accessories Suppliers in Dubai
SKU: 50800 -
-
