Window Air Conditioner Fan Motor Replacement Single Phase Asynchronous


Window Air Conditioner Fan Motor Replacement Single Phase Asynchronous

Product Features:

1. Use NSK low noise high quality rolling bearing.
2. Nickel plating for shaft, electrophoretic coating for enclosure.
3. Reasonable structure, high efficiency, low temperature rise, low noise, small vibration.

Technical Parameters

Model Number Voltage

/V

Frequency

/Hz

Power

/HP

Speed

/RPM

Rotation Capacitor

/MDF/VAC

OEM Model
YDK140-120-6A 208-230 60 1/6 1075/2 SPD REVERSIBLE 5/370 PM310668
YDK140-150-6A 208-230 60 1/5 1075/2 SPD REVERSIBLE 5/370 PM310543
YDK140-185-6A3 208-230 60 1/4 1075 REVERSIBLE 5/370 5KCP39EGP697T
YDK140-245-6A2 208-230 60 1/3 1075/3 SPD REVERSIBLE 7.5/370 FASCO D923
YSK140-120-6A 208-230 60 1/6 1095/3 SPD CCW-LE 5/370 5KCP39DGS008T
YSK140-150-6A 208-230 60 1/5 1115/3 SPD CW-LE 5/370 5KCP39FGM4440
YSK140-180-6A 208-230 60 1/4 1075/3 SPD CCW-LE 5/370 5KCP39FG5829ET
YSK140-185-6A 208-230 60 1/4 1100/2 SPD CW-LE 5/370 5KCP39FGK111T
YSK140-245-6A 208-230 60 1/3 1120/3 SPD CCW-LE 5/370 5KCP39HGM307AT
YSK140-375-6A 208-230 60 1/2 1075 REVERSIBLE 10/370 5KCP39MKG209T
YSK140-550-6A 208-230 60 3/4 1075 REVERSIBLE 15/370 5KCP39PGM602T
YSK140-735-6A 208-230 60 1 1125 CW-LE 25/440 5KCP39SFU286S



Note: Listed are representative motors, only for reference, dimensions can be customized according to customer requirements, OEM & ODM offered.



Product Applications:

1. Window type air conditioner.

2. Fresh air ventilation system.

3. Air filtration and purification.

4. To ensure the quality of the indoor air.

5. To ensure that the indoor hot and cold load (temperature) is basically not affected by the new wind.



SKU: YDK140 YSK140 series Categories: ,
